8-Port 10/100/1000T 802.3at PoE + 1-Port Uplink Ethernet + 1-Port Gigabit SFP Ethernet Switch

Model

LNK-8GP1G1SFP

Product

8+1+1 PoE Switch

Fixed Port

8*10/100/1000Base-TX PoE port (Data/Power)

1*10/100/1000Base-TX uplink RJ45 port (Data)

1*1000M SFP

PoE ports

1-8 port supports PoE (optional first port outputs HiPoE-60W)

Function

N:(Standard normal)

V:(Port isolation)

P:(Flow Control mode)

Network Protocol

IEEE 802.3

IEEE 802.3i 10BASE-T

IEEE 802.3u 100BASE-TX

IEEE 802.3ab 1000BASE-T

IEEE 802.3x

IEEE 802.3z 1000BASE-X

IEEE 802.3af/at

PoE Standard

IEEE802.3af/at

Power Pin

Default 1/2(+),3/6(-); Optional 4/5(+),7/8(-)

Single port power

Average 15.4W; MAX 30W

Total power/Input voltage

MAX 150W (AC100-240V 50/60HZ)

Watt

Standby Power Consumption: ≤8W;

LED Indicator

POWER: Power LED (optional over-power LED)

Uplink:(Link LED=10/100M Link, 1000M=Gigabit Link)

9:(SFP LED)

Port: (Orange=PoE LED; Green=Link LED)

Power Input

Built-in power AC: 100～240V 50-60Hz 1A

Operating Temperature/Humidity

-10～+55°C; 5%～90% RH Non coagulation

Storage Temperature/Humidity

-40～+75°C; 5%～95% RH Non coagulation

Product size/Packing size(L*W*H)

210mm*140mm*45mm

270mm*220mm*70mm

N.W/G.W(kg)

1.1kg/1.4kg

Installation

Desktop (optional wall mount machine hangers)

Lightning protection level

3KV 8/20us;

IP30

Certificate

CE mark, commercial; CE/LVD EN60950;

FCC Part 15 Class B; RoHS;

Warranty

Whole device for 1 year (Accessories not included)
