Cloud managed Multi-function HDMI Fiber Converter 1Ch 1080P HDMI + USB KVM + 1Ch RS232 + 1Ch Bidi Stereo Audio + GPIO

  • 1
  • 2

Brand Name : E-link

Model Number : LNK-KVM-HDMI-1D1BA1GO

Certification : CE, FCC, Rohs

Place of Origin : China

MOQ : 1pcs

Price : negotiation

Payment Terms : L/C,T/T,Western Union,MoneyGram,PayPal

Supply Ability : 100000PCS/Month

Delivery Time : 7-10 working days

Packaging Details : Industrial PoE Switch Standard Carton Packaging

Dimension (LxWxH) : 168*115*28mm

Operating Temperature : -5℃ ~ +70℃

Power Supply : DC 12V/1A

The warranty : 1-year warranty

Transmission distance : standard 10km

Interface bandwidth : 3Gbps

Contact Now

Cloud managed Multi-function HDMI Fiber Converter
1Ch 1080P HDMI + USB KVM + 1Ch RS232 + 1Ch Bidi Stereo Audio + GPIO

Product Advantages

► Transmits HDMI video signals up to 20km over one fiber optic cable; Support HDMI loop out

► Support video resolution up to 1920*1080P@60Hz;

► Support keyboard and mouse signal transmission;

► Support external bi-directional stereo audio;

► Support RS232 signal unidirectional transmission, baud rate self-adaptive;

► Support general-purpose input/output (GPIO) signal;

► Compliance with HDMI1.4 and HDCP 1.2 standard;

► Support 4U rack-mount


Technical Indexes


Parameter

Description

Video

Standards

HDMI 1.4; HDCP 1.2

Maximum pixel clock

165MHz

Maximum data rate

2.97Gbps

Resolution

1920*1080@60Hz 1920*1080@50Hz

1920*1080@30Hz 1920*1080@25Hz

1920*1080@24Hz

1080I@60Hz 1080I@50Hz

1280*720@60Hz 1280*720@50Hz

Connector

HDMI

Impedance

100Ω

Audio

Interface

3.5mm earphone seat

Signal type

Stereo

K/M(Optional)

Interface

To PC: MINI-USB

To keyboard and mouse: USB-A

GPIO

Interface

Industrial terminal

RS232

Interface

Industrial terminal

Signal direction

Unidirectional

Baud rate

Self-adaptive, Max:115200bps

Data bits

8

Optical fiber

Interface

LC connector

Fiber type

Single-mode single fiber

Wavelength

Single-mode 1310nm

Interface bandwidth

3Gbps

Transmission distance

standard 10km

Management

Cloud management

Management Platform

Manage and monitor working status of

The devices.

Screen

OLED display

Display different information of Video,

Audio, RS232, Fiber, Power etc

Cloud managed Multi-function HDMI Fiber Converter 1Ch 1080P HDMI + USB KVM + 1Ch RS232 + 1Ch Bidi Stereo Audio + GPIOOther

Power supply

The power adapter: DC 12V/1A

Power dissipation

MAX 6W

Temperature

Operating: -5℃ ~ +70℃

Humidity

Operating: 5% ~ 90%

Dimension (LxWxH)

168*115*28mm

The warranty

1-year warranty

Overview

The LNK-KVM-HDMI-1D1BA1GO Series are cloud managed multi-function HD Video Fiber optic extender which provides extension of HDMI signals long distances over one fiber optic cable, it supports high resolution up to 1080P, KVM, RS232, GPIO signal and external audio transmission function. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security.


Application

Cloud managed Multi-function HDMI Fiber Converter 1Ch 1080P HDMI + USB KVM + 1Ch RS232 + 1Ch Bidi Stereo Audio + GPIO

Ordering Information

Model

Description

LNK-KVM-HDMI-1D1BA1GO

1Ch 1080P HDMI + 1Ch USB KVM + 1Ch RS232 + 1Ch Bidi Stereo Audio + 1Ch GPIO over Fiber Extender, HDMI Loop Out, SMF, 20KM

LNK-HDMI-1D1BA

1Ch 1080P HDMI + 1Ch RS232 + 1Ch Bidi Stereo Audio over Fiber Extender, HDMI Loop Out, SMF, 20KM
