10Gb/s 40km CWDM SFP+ Transceiver

Name: 10Gbs 40km CWDM SFP Transceiver
Brand: E-link
Price: 1 USD

10Gb/s 40km CWDM SFP+ Transceiver Manufactures

Brand Name : E-link

Model Number : LNK-CSFP-10Gxx-40

Certification : CE, FCC, RoHS

Place of Origin : China

MOQ : 1pcs

Price : Negotiated

Payment Terms : T/T,PayPal

Supply Ability : 1000pcs/mouth

Delivery Time : 3-12working days

Packaging Details : standard export package

Temperature : 0℃ To 70℃

Warranty : 3 Years

Power Dissipation : <1.5W

Weight : 0.025Kg

Product Type : SFP Fiber Transceivers

Contact Now

10Gb/s 40km CWDM SFP+ Transceiver

Advantage

Ø Supports 9.95 to 11.3Gb/s bit rates

Ø Hot-Pluggable

Ø Duplex LC connector

Ø 1270～1610nm CWDM DFB transmitter, PIN photo-detector

Ø SMF links up to 10km

Ø Temperature Range: 0~ 70°C

Ø RoHS compliant

Overview

E-LINK's LNK-CSFP-10Gxx-40 is a very compact 10Gb/s optical transceiver module

for serial optical communication applications at 10Gb/s. The LNK-CSFP-10Gxx-40

converts a 10Gb/s serial electrical data stream to 10Gb/s optical output signal and a

10Gb/s optical input signal to 10Gb/s serial electrical data streams. The high speed

10Gb/s electrical interface is fully compliant with SFI specification.

Technical Indexes

Absolute Maximum Ratings

Parameter	Symbol	Min.	Typical	Max.	Unit
Storage Temperature	T_S	-40		+85	°C
Case Operating Temperature	T_A	0		70	°C
Maximum Supply Voltage	Vcc	-0.5		4	V
Relative Humidity	RH	0		85	%

Application

Ø 10GBASE-ER/EW Ethernet

Ø Sonet OC-192/SDH

Ø 10G Fibre channel

Ø CWDM Networks

10Gb/s 40km CWDM SFP+ Transceiver Images
