Industrial Hardened Ethernet Switch 8 Port 10 100 1000T + 4 Port 1G SFP + 2 Port 10G SFP+

Product Categories

E-link China Technology Co.,LTD

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: Industrial Hardened Ethernet Switch 8 Port 10 100 1000T 4 Port 1G SFP 2 Port 10G SFP
Brand: E-link
Price: 139 USD

Brand Name : E-link

Model Number : LNK-IMC2X4S8G

Certification : CE

Place of Origin : China

MOQ : 1pcs

Price : USD139/PCS

Payment Terms : L/C, T/T, Western Union, MoneyGram, PayPal

Supply Ability : 1000000PCS/Month

Delivery Time : 7-10 working days

Packaging Details : Industrial Ethernet Switch Standard Carton Packaging

RJ45 Connector : 8

Optical Port : 4 x 1000Base-X SFP 2 x 10G Base-SR/LR SFP+

Memory : 2.75M bits

Max Packet : 9K

Power : 12~48VDC

Temperature : -40℃~80℃

Contact Now

Industrial 8-Port 10/100/1000T + 4-Port 1G SFP + 2-Port 10G SFP+ Ethernet Switch

Industrial Ethernet Switch Advantages:

8x10/100/1000Base-T + 4x1000Base-X SFP + 2x 10GBase-SR/LR SFP+
10/100/1000Mbps RJ45 Port supports Full/Half-duplex, Auto-negotiation, Auto MDI/MDIX
IP40 Aluminum Case
Supports DIN-Rail installation
-40°C to 80°C (-40°F to 176°F) operating temperature

Technical Indexes

Interface
Connector:	8 x RJ45
Optical Port:	4 x 1000Base-X SFP 2 x 10G Base-SR/LR SFP+
Environmental
Operating Temperature:	-40°C to 80°C (-40°F to 176°F)
Storage Temperature:	-40°C to 85°C (-40°F to 185°F)
Relative Humidity:	5% to 95% non-condensing
MTBF	> 200,000 hrs
Electrical and Mechanical
Input Power:	12~48VDC, Redundant Power (6-pin Terminal Block)
Power Consumption:	16W Max.
Protection:
Power Input Overload:	Automatic Resettable
Reverse Polarity:	Present
LED Indicators:
Power:	Power Status
Ethernet (Per Port):	Link/Activity
Fiber:	Gigabit SFP Port: F1~F4
Fiber:	10G SFP+ Port: G1, G2
Dimensions (WxDxH):	149 x 114 x 50 mm
Weight:	0.55Kg
Casing:	Aluminum Case
Mounting Options:	DIN-Rail mount

Overview

LNK-IMC2X4S8G Series is 8-port 10/100/1000Base-T + 4-port 1000Base-X SFP + 2-port 10G Base-SR/LR SFP+ hardened

Ethernet switch.

Industrial Hardened Ethernet Switch 8 Port 10 100 1000T + 4 Port 1G SFP + 2 Port 10G SFP+

Ordering Information

Model	Description
LNK-IMC2X4S8G	Industrial 8-Port 10/100/1000T + 4-Port 1G SFP + 2-Port 10G SFP+ Ethernet Switch
SFP Options	SFP option. Please select your SFP on our SFP Options Page
SFP Options	SFP module is to be purchased separately.
Mounting Options	Default DIN-Rail Bracket installed
Power Options	DIN-Rail Power Supply. Open Wire for Terminal Block.
Power Options	Power Supply is to be purchased separately.
